Activated Carbon Adsorption Box

Description:

Product Introduction

Activated Carbon Adsorption Box is dry waste gas purification equipment filled with high iodine value activated carbon inside. It relies on porous carbon to adsorb VOC, organic odor, dye waste gas and small particle pollutants in industrial exhaust, widely matched with spray booth, printing workshop, chemical small waste gas treatment.

Polluted gas enters the box, fully passes through multi-layer carbon filter, harmful organic substances are trapped on carbon surface, clean gas is discharged up to standard. The box body adopts detachable design, convenient for carbon replacement, low operation cost.

Core Advantages

  1. Developed activated carbon pore structure, strong adsorption capacity for VOC and peculiar smell
  2. Carbon steel sealed box, anti-leakage, small occupied area, easy to install
  3. Quick-open access door, simple replacement of activated carbon without complex tools
  4. No water circulation system, no secondary wastewater pollution, low energy consumption
  5. Customizable air volume from 1000–30000 m³/h

Application Scenarios

Spray painting line, printing factory, leather processing, laboratory waste gas, sewage station odor control, food fermentation odor removal, small chemical plant VOC treatment

Technical Parameters

  • Box Material: Carbon Steel / SUS304 Stainless Steel
  • Filler: Coal-based / Coconut Shell Activated Carbon (Iodine value 900–1200mg/g)
  • Treatment Air Volume: Customized 1000–30000 m³/h
  • Purification Efficiency: ≥95%
  • Certifications: CE, ISO9001
  • Service Life: 10–15 years

Packaging & Delivery

Packed with standard fumigated export wooden case, shockproof foam inside to protect carbon box and air duct parts.

Loading Port: Qingdao Port

Lead Time: 10–20 working days after deposit confirmation
